| Model | P-100ILA | |||
|---|---|---|---|---|
| Capacity | Ø15-100 mm | |||
| 15-80mm | ||||
| Blade Speed | 40 – 160 RPM | |||
| Saw Blade Size | Ø360 x T2.6 x 2.25t mm. | |||
| Motors | Blade Motor | 11 Kw (15 HP) | ||
| Hydraulic Pump Motor | 2.2 Kw (3 HP) | |||
| Servo Motor | Blade Feed | 1.5KW | ||
| Bar Feed | 1.5KW | |||
| Blade Feed nBar Feed |
Servo motor and ball screw | |||
| Automatic Feed Length | Single feed8-600mm. nMultiple feed ~3000mm |
|||
| Cooling | Air compressed oil mist | |||
| Machine Weight | 3900 kgs | |||
| Floor Space | Machine | 2900W x 1900L | ||
| With Loading Table | 2900W x 7038L | |||
